Product Details
Place of Origin: China
Brand Name: WEYO
Model Number: Standard low-pressure (300 psi) ultra-high purity diaphragm valve
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Packaging Details: Customized packaging to protect products
Delivery Time: 7 - 15 days for small orders, 15 - 30 days for large orders
Payment Terms: T/T, L/C
Supply Ability: 5000 units per month for small parts. 1000 units per month for large parts
Standard low-pressure (300 psi) ultra-high purity diaphragm valve , suitable for high-purity and ultra-high-purity applications
Standard low-pressure (300 psi) ultra-high purity diaphragm valve, designed and manufactured strictly according to industry standards.
Diaphragm sealing, suitable for high-purity and ultra-high-purity applications.
| number | name | matterial |
1 |
fittings body |
SS316 |
| 2 | sphere | SS316 |
| 3 | matrix | SS316 |
4 |
Ball gasket | PTFE/PEEK |
5 |
O-ring | neoprene |
6 |
Front ferrule | SS316 |
7 |
Rear ferrule | SS316 |
8 |
Ferrule nut | SS316 |
9 |
Gasket | SS316 |
10 |
Gasket | SS316 |
11 |
Tightening nut | SS316 |
12 |
Joystick | sibley alloy |
13 |
packing | PTFE/PEEK |
14 |
installing nut | SS316 |
| 15 | valve stem | SS316 |
| model | mm | size | Panel installation hole size | |||||||||||||||||
| A | B | C | C | |||||||||||||||||
| BV300-TF04-TF04 | 5 | 51.6 | 45.7 | 20 | 10 | φ14.5 | ||||||||||||||
| BV300-TF06-TF06 | 7.5 | 56.6 | 47.7 | 20 | 12 | φ16.5 | ||||||||||||||
| BV300-TF08-TF08 | 10 | 64 | 60 | 23.02 | 14.5 | φ19.5 | ||||||||||||||
Ordering Guide
| Ex. SS BV300 -TF4 -TF4 | ||||||||||||||||||||
| Parent material product line nlet connection Exhaust connector | ||||||||||||||||||||
SS:stainless steel |
BV300 |
TF02:1/8"ferrule fitting TF04:1/4"ferrule fitting TF06:3/8"ferrule fitting TF08:1/2"ferrule fitting NPT04:1/4"NPTnternal thread NPT08:1/2"NPTnternal thread Other connectors are available for selection |
TF02:1/8"ferrule fitting TF04:1/4"ferrule fitting TF06:3/8"ferrule fitting TF08:1/2"ferrule fitting NPT04:1/4"NPTnternal thread NPT08:1/2"NPTnternal thread Other connectors are available for selection |
|||||||||||||||||
Air inlet/outlet joint
